Audio-Technica AT120E
A moving magnet phono cartridge with elliptical stylus, noted for detailed sound and use as an upgrade path.
Overview
The Audio-Technica AT120E is a moving magnet phono cartridge designed for high-fidelity vinyl playback. Manufactured by Audio-Technica, it features an elliptical stylus and was recognized for delivering an open, detailed audio presentation. It was regarded as an upgrade option over entry-level cartridges like the OM10 and considered comparable to other well-regarded models of its era. Users reported strong performance on turntables such as the Technics SL-1700mk2, though some noted minor treble limitations.
Specifications
| Product type | Phono cartridge / Moving Magnet cartridge |
| Stylus type | Elliptical |
| Output voltage | 4.0 mV |
| Channel separation | 25 dB |
| Channel balance | 1.5 dB |
| Frequency response | 20-25,000 Hz |
| Tracking force range | 1.4-1.6 g |
| Load impedance | 47k ohms |
| Stylus tip mass | 0.6 mg |
| Compliance | 10 x 10-6 cm/dyne |
| Internal impedance | 2,200 ohms |
| Recommended load capacitance | 100-200 pF |
| Stylus replacement | VMN30EN |
| Original price | £120 |
Market
The AT120E was priced at £120 at launch and is noted as a cartridge with available stylus replacements, specifically the VMN30EN model, supporting continued use and maintenance.
