Altec Lansing Model 305
A 3-way bookshelf speaker system with airtight enclosure and advanced diaphragm materials, sold in Japan around 1990.
Overview
The Altec Lansing Model 305 is a 3-way, 3-speaker bookshelf system designed for high-fidelity audio reproduction. Built with an airtight (hermetically sealed) enclosure, it emphasizes controlled bass response and acoustic precision. This model was priced at ¥135,000 per unit in the Japanese market around 1990, indicating its position as a premium compact speaker system during that era.
Specifications
| Woofer | 25 cm cone type |
| Midrange | 5 cm Dome Type |
| Tweeter | 2.5 cm dome type |
| Impedance | 8 Ω |
| Crossover frequency | 550 Hz, 3.5 kHz |
| External dimensions | Width 368 x Height 686 x Depth 305 mm |
| Weight | 20.0kg |
Design
The Model 305 features a hermetically sealed enclosure for tight, resonance-controlled bass performance. The woofer uses a carbon fiber diaphragm, while the midrange and tweeter employ polyimide resin diaphragms enhanced with a titanium vapor deposition process. This construction suggests a focus on rigidity and transient response. The cabinet is finished in walnut natural wood, blending aesthetic warmth with acoustic functionality.
Market
Priced at ¥135,000 around 1990, the Model 305 was positioned as a high-end bookshelf speaker in the Japanese market, likely targeting audiophiles seeking compact yet technically advanced systems.
